O Navigation Drawer é um componente que permite construir um menu lateral que desliza no sentido esquerda para a direita. É possível criar um Navigation Drawer do zero, mas atualmente, é disponibilizado o template pronto do Navigation Drawer quando você cria um projeto no Android Studio. Dessa forma, o trabalho fica compreendido em entender as funções de vários elementos que o compõe. Isto pode ser visto logo a seguir nos exemplos práticos.

Para mais detalhes:

GOOGLE MATERIAL DESIGN. Navigation Drawer. Disponível em: https://material.io/components/navigation-drawer. Acessado em: 21 ago. 2025.

Exemplo prático 1:

string.xml

<resources>
    <string name="app_name">NavDrawerSimples</string>
    <string name="navigation_drawer_open">Abrir menu</string>
    <string name="navigation_drawer_close">Fechar menu</string>
    <string name="flamengo">Flamengo</string>
    <string name="corinthians">Corinthians</string>
    <string name="goias">Goiás</string>
</resources>

colors.xml

<?xml version="1.0" encoding="utf-8"?>
<resources>
    <color name="black">#FF000000</color>
    <color name="white">#FFFFFFFF</color>
    <color name="green">#8BC34A</color>
</resources>

nav_menu.xml (pasta menu)

<menu xmlns:android="http://schemas.android.com/apk/res/android">
    <item
        android:id="@+id/nav_flamengo"
        android:icon="@drawable/ic_launcher_foreground"
        android:title="@string/flamengo" />
    <item
        android:id="@+id/nav_corinthians"
        android:icon="@drawable/ic_launcher_foreground"
        android:title="@string/corinthians" />
    <item
        android:id="@+id/nav_goias"
        android:icon="@drawable/ic_launcher_foreground"
        android:title="@string/goias" />
</menu>

nav_header.xml (pasta layout)

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:orientation="vertical"
    android:padding="16dp"
    android:background="@color/green">
    <ImageView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:src="@drawable/ic_launcher_background" />
    <TextView
        android:id="@+id/header_title"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Times de Futebol"
        android:textColor="@color/white"
        android:textSize="20sp"
        android:textStyle="bold" />
    <TextView
        android:id="@+id/header_subtitle"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Escolha seu time"
        android:textColor="@color/white"
        android:textSize="16sp" />
</LinearLayout>

fragment_corinthians.xml

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    android:padding="16dp">
    <ImageView
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:src="@drawable/ic_launcher_foreground" />
    <TextView
        android:id="@+id/text_corinthians"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Corinthians"
        android:textSize="20sp" />
</LinearLayout>

fragment_flamengo.xml

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    android:padding="16dp">
    <ImageView
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:src="@drawable/ic_launcher_foreground" />
    <TextView
        android:id="@+id/text_corinthians"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Flamengo"
        android:textSize="20sp" />
</LinearLayout>

fragment_goias.xml

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    android:padding="16dp">
    <ImageView
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:src="@drawable/ic_launcher_foreground" />
    <TextView
        android:id="@+id/text_goias"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Goiás"
        android:textSize="20sp" />
</LinearLayout>

nav_header.xml (pasta layout)

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:orientation="vertical"
    android:padding="16dp"
    android:background="@color/green">
    <ImageView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:src="@drawable/ic_launcher_background" />
    <TextView
        android:id="@+id/header_title"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Times de Futebol"
        android:textColor="@color/white"
        android:textSize="20sp"
        android:textStyle="bold" />
    <TextView
        android:id="@+id/header_subtitle"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Escolha seu time"
        android:textColor="@color/white"
        android:textSize="16sp" />
</LinearLayout>

CorinthiansFragment.java

import android.os.Bundle;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import androidx.fragment.app.Fragment;
public class CorinthiansFragment extends Fragment {
    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container,
                             Bundle savedInstanceState) {
        return inflater.inflate(R.layout.fragment_corinthians, container, false);
    }
}

FlamengoFragment.java

import android.os.Bundle;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import androidx.fragment.app.Fragment;
public class FlamengoFragment extends Fragment {
    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container,
                             Bundle savedInstanceState) {
        return inflater.inflate(R.layout.fragment_flamengo, container, false);
    }
}

GoiasFragment.java

import android.os.Bundle;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import androidx.fragment.app.Fragment;
public class GoiasFragment extends Fragment {
    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container,
                             Bundle savedInstanceState) {
        return inflater.inflate(R.layout.fragment_goias, container, false);
    }
}

MainActivity.java

import android.os.Bundle;
import android.view.MenuItem;
import androidx.activity.OnBackPressedCallback;
import androidx.appcompat.app.AppCompatActivity;
import androidx.core.view.GravityCompat;
import androidx.drawerlayout.widget.DrawerLayout;
import androidx.fragment.app.Fragment;
import com.google.android.material.navigation.NavigationView;
public class MainActivity extends AppCompatActivity {
    private DrawerLayout drawerLayout;
    private NavigationView navigationView;
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        drawerLayout = findViewById(R.id.drawer_layout);
        navigationView = findViewById(R.id.navigation_view);
        navigationView.setNavigationItemSelectedListener(item -> {
            Fragment selectedFragment = null;
            int id = item.getItemId();
            if (id == R.id.nav_flamengo) {
                selectedFragment = new FlamengoFragment();
            } else if (id == R.id.nav_corinthians) {
                selectedFragment = new CorinthiansFragment();
            } else if (id == R.id.nav_goias) {
                selectedFragment = new GoiasFragment();
            }
            if (selectedFragment != null) {
                getSupportFragmentManager()
                        .beginTransaction()
                        .replace(R.id.fragment_container, selectedFragment)
                        .commit();
            }
            drawerLayout.closeDrawer(GravityCompat.START);
            return true;
        });
        if (savedInstanceState == null) {
            getSupportFragmentManager()
                    .beginTransaction()
                    .replace(R.id.fragment_container, new FlamengoFragment())
                    .commit();
        }
        getOnBackPressedDispatcher().addCallback(this,
                new OnBackPressedCallback(true) {
            @Override
            public void handleOnBackPressed() {
                if (drawerLayout.isDrawerOpen(GravityCompat.START)) {
                    drawerLayout.closeDrawer(GravityCompat.START);
                } else {
                    // Fecha a Activity
                    finish();
                }
            }
        });
    }
}//class

Exemplo prático 2 (Elementos do Navigation Drawer):

No arquivo Gradle a nível de módulo, ative o DataBinding

  buildFeatures {
        viewBinding = true
    }

Na pasta layout adicione:

activty_main.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.drawerlayout.widget.DrawerLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/drawer_layout"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:fitsSystemWindows="true"
    tools:openDrawer="start">
    <include
        android:id="@+id/app_bar_main"
        layout="@layout/app_bar_main"
        android:layout_width="match_parent"
        android:layout_height="match_parent" />
    <com.google.android.material.navigation.NavigationView
        android:id="@+id/nav_view"
        android:layout_width="wrap_content"
        android:layout_height="match_parent"
        android:layout_gravity="start"
        android:fitsSystemWindows="true"
        app:headerLayout="@layout/nav_header_main"
        app:menu="@menu/activity_main_drawer" />
</androidx.drawerlayout.widget.DrawerLayout>

app_bar_main.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.coordinatorlayout.widget.CoordinatorLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".MainActivity">
    <com.google.android.material.appbar.AppBarLayout
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:theme="@style/Theme.ExemploNavigationDrawer_01.AppBarOverlay">
        <androidx.appcompat.widget.Toolbar
            android:id="@+id/toolbar"
            android:layout_width="match_parent"
            android:layout_height="?attr/actionBarSize"
            android:background="?attr/colorPrimary"
            app:popupTheme="@style/Theme.ExemploNavigationDrawer_01.PopupOverlay" />
    </com.google.android.material.appbar.AppBarLayout>
    <include layout="@layout/content_main" />
    <com.google.android.material.floatingactionbutton.FloatingActionButton
        android:id="@+id/fab"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_gravity="bottom|end"
        android:layout_marginEnd="@dimen/fab_margin"
        android:layout_marginBottom="16dp"
        app:srcCompat="@android:drawable/ic_menu_agenda" />
</androidx.coordinatorlayout.widget.CoordinatorLayout>

content_main.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    app:layout_behavior="@string/appbar_scrolling_view_behavior"
    tools:showIn="@layout/app_bar_main">
    <fragment
        android:id="@+id/nav_host_fragment_content_main"
        android:name="androidx.navigation.fragment.NavHostFragment"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        app:defaultNavHost="true"
        app:layout_constraintLeft_toLeftOf="parent"
        app:layout_constraintRight_toRightOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        app:navGraph="@navigation/mobile_navigation" />
</androidx.constraintlayout.widget.ConstraintLayout>

nav_header_main.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent"
    android:layout_height="@dimen/nav_header_height"
    android:background="@drawable/side_nav_bar"
    android:gravity="bottom"
    android:orientation="vertical"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:theme="@style/ThemeOverlay.AppCompat.Dark">
    <ImageView
        android:id="@+id/imageView"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:contentDescription="@string/nav_header_desc"
        android:paddingTop="@dimen/nav_header_vertical_spacing"
        app:srcCompat="@mipmap/ic_launcher_round" />
    <TextView
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:paddingTop="@dimen/nav_header_vertical_spacing"
        android:text="@string/nav_header_title"
        android:textAppearance="@style/TextAppearance.AppCompat.Body1" />
    <TextView
        android:id="@+id/textView"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="@string/nav_header_subtitle" />
</LinearLayout>

na pasta drawable, crie o arquivo side_nav_bar.xml

<shape xmlns:android="http://schemas.android.com/apk/res/android"
    android:shape="rectangle">
    <gradient
        android:angle="135"
        android:centerColor="@color/yellow_200"
        android:endColor="@color/yellow_500"
        android:startColor="@color/yellow_700"
        android:type="linear" />
</shape>

fragment_cake.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    tools:context=".ui.coffee.CoffeeFragment">
    <ImageView
        android:layout_width="match_parent"
        android:layout_height="100dp"
        android:id="@+id/image_cake"
        android:src="@drawable/ic_launcher_foreground"/>
    <TextView
        android:id="@+id/text_cake"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginStart="8dp"
        android:layout_marginTop="8dp"
        android:layout_marginEnd="8dp"
        android:textAlignment="center"
        android:textSize="20sp"
         />
</LinearLayout>

fragment_coffee.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    tools:context=".ui.coffee.CoffeeFragment">
    <ImageView
        android:layout_width="match_parent"
        android:layout_height="100dp"
        android:id="@+id/image_coffee"
        android:src="@drawable/ic_launcher_foreground"/>
    <TextView
        android:id="@+id/text_coffee"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginStart="8dp"
        android:layout_marginTop="8dp"
        android:layout_marginEnd="8dp"
        android:textAlignment="center"
        android:textSize="20sp"
        />
</LinearLayout>

Na pasta menu adicione:

activity_main_drawer.xml

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    tools:showIn="navigation_view">
    <group android:checkableBehavior="single">
        <item
            android:id="@+id/nav_cake"
            android:icon="@drawable/coffee"
            android:title="@string/menu_cake" />
        <item
            android:id="@+id/nav_coffee"
            android:icon="@drawable/strawberry_cake"
            android:title="@string/menu_coffee" />
    </group>
</menu>

main.xml

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto">
    <item
        android:id="@+id/action_settings"
        android:orderInCategory="100"
        android:title="@string/action_settings"
        app:showAsAction="never" />
    <item
        android:id="@+id/action_contact"
        android:orderInCategory="100"
        android:title="@string/contact"
        app:showAsAction="never" />
</menu>

Na paste navigation adicione:

mobile_navigation.xml

<?xml version="1.0" encoding="utf-8"?>
<navigation xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/mobile_navigation"
    app:startDestination="@+id/nav_cake">
    <fragment
        android:id="@+id/nav_cake"
        android:name="com.example.exemplonavigationdrawer_01.ui.cake.CakeFragment"
        android:label="@string/menu_cake"
        tools:layout="@layout/fragment_cake" />
    <fragment
        android:id="@+id/nav_coffee"
        android:name="com.example.exemplonavigationdrawer_01.ui.coffee.CoffeeFragment"
        android:label="@string/menu_coffee"
        tools:layout="@layout/fragment_coffee" />
</navigation>

Outros arquivos a serem adicionados no projeto:

colors.xml

<?xml version="1.0" encoding="utf-8"?>
<resources>
    <color name="yellow_200">#FFEB3B</color>
    <color name="yellow_500">#FFC107</color>
    <color name="yellow_700">#FF9800</color>
    <color name="teal_200">#FF03DAC5</color>
    <color name="teal_700">#FF018786</color>
    <color name="black">#FF000000</color>
    <color name="white">#FFFFFFFF</color>
</resources>

strings.xml

<resources>
    <string name="app_name">ExemploNavigationDrawer_01</string>
    <string name="navigation_drawer_open">Open navigation drawer</string>
    <string name="navigation_drawer_close">Close navigation drawer</string>
    <string name="nav_header_title">Android Studio</string>
    <string name="nav_header_subtitle">android.studio@android.com</string>
    <string name="nav_header_desc">Navigation header</string>
    <string name="action_settings">Settings</string>
    <string name="menu_cake">Cake</string>
    <string name="menu_coffee">Coffee</string>
    <string name="contact">Contact</string>
</resources>

dimens.xml

<resources>
    <!-- Default screen margins, per the Android Design guidelines. -->
    <dimen name="activity_horizontal_margin">16dp</dimen>
    <dimen name="activity_vertical_margin">16dp</dimen>
    <dimen name="nav_header_vertical_spacing">8dp</dimen>
    <dimen name="nav_header_height">176dp</dimen>
    <dimen name="fab_margin">16dp</dimen>
</resources>

MainActivity.java

import android.os.Bundle;
import android.util.Log;
import android.view.MenuItem;
import android.view.View;
import android.view.Menu;
import android.widget.Toast;
import com.google.android.material.snackbar.Snackbar;
import com.google.android.material.navigation.NavigationView;
import androidx.annotation.NonNull;
import androidx.navigation.NavController;
import androidx.navigation.Navigation;
import androidx.navigation.ui.AppBarConfiguration;
import androidx.navigation.ui.NavigationUI;
import androidx.drawerlayout.widget.DrawerLayout;
import androidx.appcompat.app.AppCompatActivity;
import com.example.exemplonavigationdrawer_01.databinding.ActivityMainBinding;
public class MainActivity extends AppCompatActivity {
    private AppBarConfiguration mAppBarConfiguration;
    private ActivityMainBinding binding;
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        Log.e("MainActivity","onCreate");
        binding = ActivityMainBinding.inflate(getLayoutInflater());
        setContentView(binding.getRoot());
        setSupportActionBar(binding.appBarMain.toolbar);
        binding.appBarMain.fab.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                Snackbar.make(view, "Replace with your own action", Snackbar.LENGTH_LONG)
                        .setAction("Action", null)
                        .setAnchorView(R.id.fab).show();
            }
        });
        DrawerLayout drawer = binding.drawerLayout;
        NavigationView navigationView = binding.navView;
        // Passing each menu ID as a set of Ids because each
        // menu should be considered as top level destinations.
        mAppBarConfiguration = new AppBarConfiguration.Builder(
                R.id.nav_cake, R.id.nav_coffee)
                .setOpenableLayout(drawer)
                .build();
        navigationView.setItemIconTintList(null); //para os icones ficarem coloridos
        NavController navController = Navigation.findNavController(this, R.id.nav_host_fragment_content_main);
        NavigationUI.setupActionBarWithNavController(this, navController, mAppBarConfiguration);
        NavigationUI.setupWithNavController(navigationView, navController);
    }
    @Override
    public boolean onCreateOptionsMenu(Menu menu) {
        // Inflate the menu; this adds items to the action bar if it is present.
        getMenuInflater().inflate(R.menu.main, menu);
        return true;
    }
    @Override
    public boolean onOptionsItemSelected(@NonNull MenuItem item) {
        if(item.getItemId() == R.id.action_settings){
            Toast.makeText(getApplicationContext(),"Settings",
                    Toast.LENGTH_SHORT).show();
        }
        if(item.getItemId() == R.id.action_contact){
            Toast.makeText(getApplicationContext(),"Contact",
                    Toast.LENGTH_SHORT).show();
        }
        return super.onOptionsItemSelected(item);
    }
    @Override
    public boolean onSupportNavigateUp() {
        NavController navController = Navigation.findNavController(this, R.id.nav_host_fragment_content_main);
        return NavigationUI.navigateUp(navController, mAppBarConfiguration)
                || super.onSupportNavigateUp();
    }
}

CakeFragment.java

import android.os.Bundle;
import android.util.Log;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ImageView;
import android.widget.TextView;
import androidx.annotation.NonNull;
import androidx.annotation.Nullable;
import androidx.fragment.app.Fragment;
import androidx.lifecycle.ViewModelProvider;
import com.example.exemplonavigationdrawer_01.databinding.FragmentCakeBinding;
import com.example.exemplonavigationdrawer_01.ui.coffee.CoffeeViewModel;
public class CakeFragment extends Fragment {
    private FragmentCakeBinding binding;
    public View onCreateView(@NonNull LayoutInflater inflater,
                             ViewGroup container, Bundle savedInstanceState) {
        binding = FragmentCakeBinding.inflate(inflater, container, false);
        View root = binding.getRoot();
        Log.i("CakeFragment","onCreateView");
        return root;
    }
    @Override
    public void onViewCreated(@NonNull View view, @Nullable Bundle savedInstanceState) {
        // super.onViewCreated(view, savedInstanceState);
        CakeViewModel cakeViewModel =
                new ViewModelProvider(this).get(CakeViewModel.class);
        final TextView textView = binding.textCake;
        cakeViewModel.getText().observe(getViewLifecycleOwner(),
                textView::setText);
        final ImageView imageView = binding.imageCake;
        cakeViewModel.getInteger().observe(getViewLifecycleOwner(),imageView::setImageResource);
        Log.i("CakeFragment","onViewCreated");
    }
    @Override
    public void onDestroyView() {
        super.onDestroyView();
        binding = null;
        Log.i("CakeFragment","onDestroyView");
    }
}

CakeViewModel.java

import android.util.Log;
import androidx.lifecycle.LiveData;
import androidx.lifecycle.MutableLiveData;
import androidx.lifecycle.ViewModel;
import com.example.exemplonavigationdrawer_01.R;
public class CakeViewModel extends ViewModel {
    private final MutableLiveData<String> mText;
    private final MutableLiveData<Integer> mImage;
    public CakeViewModel() {
        mText = new MutableLiveData<>();
        mText.setValue("This is cake fragment");
        mImage = new MutableLiveData<>();
        mImage.setValue(R.drawable.strawberry_cake);
        Log.i("CakeViewModel","construtor");
    }
    public LiveData<String> getText() {
        return mText;
    }
    public LiveData<Integer> getInteger() {
        return mImage;
    }
}

CoffeeFragment.java

import android.os.Bundle;
import android.util.Log;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ImageView;
import android.widget.TextView;
import androidx.annotation.NonNull;
import androidx.annotation.Nullable;
import androidx.fragment.app.Fragment;
import androidx.lifecycle.ViewModelProvider;
import com.example.exemplonavigationdrawer_01.databinding.FragmentCoffeeBinding;
public class CoffeeFragment extends Fragment {
    private FragmentCoffeeBinding binding;
    public View onCreateView(@NonNull LayoutInflater inflater,
                             ViewGroup container, Bundle savedInstanceState) {
        binding = FragmentCoffeeBinding.inflate(inflater, container, false);
        View root = binding.getRoot();
        Log.e("CoffeeFragment","onCreateView");
        return root;
    }
    @Override
    public void onViewCreated(@NonNull View view, @Nullable Bundle savedInstanceState) {
       // super.onViewCreated(view, savedInstanceState);
        CoffeeViewModel coffeeViewModel =
                new ViewModelProvider(this).get(CoffeeViewModel.class);
        final TextView textView = binding.textCoffee;
        coffeeViewModel.getText().observe(getViewLifecycleOwner(), textView::setText);
        final ImageView imageView = binding.imageCoffee;
        coffeeViewModel.getInteger().observe(getViewLifecycleOwner(),imageView::setImageResource);
        Log.e("CoffeeFragment","onViewCreated");
    }
    @Override
    public void onDestroyView() {
        super.onDestroyView();
        binding = null;
        Log.e("CoffeeFragment","onDestroyView");
    }
}

CoffeeViewModel.java

import android.util.Log;
import androidx.lifecycle.LiveData;
import androidx.lifecycle.MutableLiveData;
import androidx.lifecycle.ViewModel;
import com.example.exemplonavigationdrawer_01.R;
public class CoffeeViewModel extends ViewModel {
    private final MutableLiveData<String> mText;
    private final MutableLiveData<Integer> mImage;
    public CoffeeViewModel() {
        mText = new MutableLiveData<>();
        mText.setValue("This is coffee fragment");
        mImage = new MutableLiveData<>();
        mImage.setValue(R.drawable.coffee);
        Log.i("CoffeeViewModel","construtor");
    }
    public LiveData<String> getText() {
        return mText;
    }
    public LiveData<Integer> getInteger() {
        return mImage;
    }
}

Animação Usando Arquivos JSON

Já vimos nos tópicos anteriores que o arquivo JSON facilita a troca de dados entre aplicativos, mas seria possível aplicá-lo em outras situações? Por exemplo: em animações? Sim, atualmente o JSON é usado também para essa finalidade, um exemplo disto é a biblioteca Lottie que renderiza animações exportadas do software Adobe After Effects.

Para saber mais detalhes sobre a biblioteca, acesse o projeto disponível no GitHub no seguinte endereço: https://github.com/airbnb/lottie-android

Exemplos práticos:

Crie um projeto na IDE;
Escolha uma Activity vazia;
No arquivo build.gradle, adicione uma dependência: dependencies

{… implementation "com.airbnb.android:lottie:4.2.2" //obter a lib …}

Clique com o botão direito do mouse na pasta res e adicione um diretório chamado raw. Coloque o arquivo json baixado neste diretório.

No arquivo activity_main.xml, acrescente a tag:

<com.airbnb.lottie.LottieAnimationView
   android:id="@+id/animation_view"
   android:layout_width="wrap_content"
   android:layout_height="wrap_content"
   app:lottie_rawRes="@raw/cube"    //onde fica o arquivo json
   app:lottie_autoPlay="true"   //iniciar a animação
   app:lottie_loop="true"   //animação continua indefinidamente
   />

Pronto, basta executar o app.

Referências do exemplo acima:

AIRBNB. Getting Started. Disponível em: https://airbnb.io/lottie/#/android. Acessado em: 10 fev. 2023.
LOTTIEFILES. Disponível em: https://lottiefiles.com/. Acessado em: 10 fev. 2023.
